$169.00 (Cable Retractor™ 2.0); the superseded 1.0 is still listed separately at $135.00 against a $169.00 compare-at · Listed and priced on Dialed Motion's own store, created March 20, 2026 and published March 21, 2026 per the store's own product data, but not orderable on Sept 26, 2026. The only buy control is a visible, disabled button reading "PREORDER OCT '26", the variant returns available:false, and a site-wide banner reads "Next Preorder Oct. 2026". That window is when ordering reopens, not a stated ship date — the brand publishes no shipping estimate for it.
A ratchet-based cable retractor sold as a standalone component rather than inside a finished machine. The brand's framing is explicit: "To allow you to design your own cable systems, we decided to make each of our components available separately." It keeps the cable tensioned, makes height adjustment quick, and extends the cable to other accessories with the flip of a switch.
Published specifications for the 2.0: product weight 3.75 lb, dimensions 7.5 x 5.75 x 1.875 in, retractor cable length 21 ft, Maximum Working Load 200 lb, statically tested to over 1,200 lb without failure. What's included is one retractor and nothing else. SKU CR2.
What the 2.0 changes over the 1.0, in the brand's own words: a removable cable ball end that "can be removed with an Allen key, allowing the cable to pass through rack holes and small openings", and a thinner cable — outer diameter reduced from 4.0 mm to 3.5 mm — for flexibility and less resistance in longer or more complex routing.
Two generations are listed at once. The Cable Retractor™ 1.0 (SKU F10001, $135.00) is still on the store, and its specifications panel publishes an older figure, "Weight Capacity: 300 lbs", with none of the 2.0 page's Load Rating & Testing explanation. The 2.0 page states the reconciliation directly: "Earlier versions of this product page referenced higher load capacities based on our internal static testing. As our testing program has evolved, we have adopted more conservative working-load ratings based on applicable ISO stationary training equipment safety factors and endurance testing." The 200 lb figure is the brand's current rating; the 300 lb figure is the one it says it has moved away from.
The compatibility note is the part to read before ordering, and the brand states it plainly: the retractor is designed to mount to Dialed Motion's own Load Pin or Trolley. Using it with equipment outside that system requires a Carabiner Adapter or a Threaded Adapter — separate purchases the headline price does not include. All four exist on the store: Carabiner Adapter $15.00, Threaded Adapter $29.00, Load Pin 2.0 $45.00, Trolley 2.0 $269.00.
Why it matters: The index has been describing this component inside three separate entries while never tracking it. The Multifly entry calls the retractor the mechanism that attachment runs its cable through and notes it "is already being licensed by other home-gym brands"; the REP x Dialed Motion Leg Developer entry describes "using a retractor for fast stack connection". The catalog was using a product as a reference point for other products without carrying it.
It also answers a question the index keeps circling — whether cable resistance is an accessory purchase or a rack purchase — with the cheapest published figure in that space. The honest version of that answer is the one the brand's own compatibility note gives: $169.00 buys the retractor, and the retractor does nothing without the rest of the system. A minimum working setup adds a Load Pin at $45.00 or a Trolley at $269.00, or an adapter for third-party equipment.
Watch for: NOTHING ON THIS STORE CAN BE ORDERED RIGHT NOW. All 16 products and all 35 variants read available:false, every buy control is disabled, and the next window is October 2026. Treat both the 2.0's $169.00 and the 1.0's $135.00 as list prices you cannot act on today.
THE TWO GENERATIONS PUBLISH DIFFERENT LOAD RATINGS. The 2.0 says Maximum Working Load 200 lb; the still-live 1.0 page says Weight Capacity 300 lbs. The brand explains the change on the 2.0 page only, so a buyer who lands on the 1.0 page sees the higher number with no context. The 200 lb figure is the current one. The brand's supporting claims — statically tested past 1,200 lb without failure, and 12,000 load cycles on the complete Ibex System at the 200 lb working load — are its own internal testing, referenced to ISO stationary training equipment safety factors but not independently verified here.
THE $135.00 ON THE 1.0 IS NOT A DISCOUNT OFF ITS OWN FORMER PRICE in any way this index can verify. Its compare-at is $169.00, which is exactly the 2.0's list price — consistent with the older generation being cleared against the current one rather than with a sale.
URL HAZARD: the 2.0's store handle contains a literal trademark character (cable-retractor™-2-0) and must be percent-encoded. The plain /products/cable-retractor URL is the 1.0, a different product with a different SKU.
Not verified: materials (the strings material, steel, aluminum and aluminium each return zero in rendered text, deep DOM and raw HTML on both pages) and any product-specific warranty. Vendor-hosted reviews show "6 reviews" with the same count on both the 1.0 and 2.0 pages, so those reviews cannot be attributed to the 2.0 specifically and no rating is recorded here.
